Perspective Aluminium Sectional Doors

Model: SA240620

Features:
1. Ultra-contemporary sectional door
2. With 20mm scratch resistant polymer double glazing
3. The minimalist look and come with the choice of clear, satin or frosted glazing
4. Electric operation as standard and included
5. To ensure a secure installation of the hinge, a rubber sealing strip is installed at the bottom of the segmented door panel.

Quantity:
Availability:





Inquire Add to Basket

Product Description

Our Advantages

● Strong technical research and development capabilities support highly customized services, ensuring 100% satisfaction of customer needs.

● Professional service and technical support team ensures effective communication and quick response to customer needs.

● Strict quality control ensures excellent product performance.

● Adequate production capacity ensures that we deliver on time and quickly.

Technical Information
Power Supply	220-240VAC / 100-120VAC
Rated Frequency	50/60Hz
Operating Temperature	-25°C to +65°C
Workplace-related Emission Value	< 59 dBA (drive only)
Degree of Protection	IP21
Max. Pull and Push Force	800N
Nominal Pulling Force	240 N
Rated Current Consumption	0.65A
Rated Power Consumption	130W
Power Consumption Standby (in power saving mode)	< 1w
Max. Speed	180mm/s
Aluminium Material	6063-T,THK 2.5mm
Door Panel THK	40mm
Reinforcement Bars THK	2.5 or 5.0mm
Tempered Glass THK	5.0mm or customized

Perspective Aluminium Sectional Doors
